Galvanized Prefab Container – Flat Pack Storage
STRUCTURE: Constituted by profiles of galvanized prepainted steel 1,5 mm thick (UNI 5753-75).
BASE: Constituted by profiles of galvanized prepainted steel 1,5 mm thick , on such structure it comes put down a corrugated sheet from solaio galvanized, Over the slab, we finish the flooring with a type wood overlay (waterproof)
EXTERNAL AND INTERNAL WALLS: Made of freeted zinc-plated steel plate, 6/10 thick.
TOP COVER: Made of freeted zinc-plated steel plate, 6/10 thick.
NOTE: Four steel hooking insert with eye, on the roof, allow to lift the container box.
|
REF |
MEASURES mm
|
INTERNAL MEASURES mm
|
Weight Kg |
|
|
CONTBOX300 |
3140x2000xh2280 |
3000x1800xh2000 |
600 |
|
|
CONTBOX400 |
4140x2000xh2280 |
4000x1800xh2000 |
800 |
|
|
CONTBOX500 |
5140x2000xh2280 |
5000x1800xh2000 |
1000 |
OTHER DIMENSIONS ON REQUEST
